ISP1521BE

USB hub controller IC, QFP-80, -0.5 to +4.6 V, 100 mA, ISP1521BE

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~1,000,000.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.00~1,000,000.00

PartNumber:: ISP1521BE

Brand:: Philips Electronics India Limited - PHILIPS | Pack: QFP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Miky's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-05-08

From Other Seller

Part Number:ISP1521BE
US $1.00 - 1,000,000.00
EKZE250ELL152MK25S

US $0.10 - 1.00 / Piece
(0) Remove
74AHC2G08VS SOP-8

US $2.00 - 2.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The ISP1521BE is a stand-alone Universal Serial Bus (USB) hub controller IC that complies with Universal Serial Bus Specification Rev. 2.0. It supports data transfer at high-speed (480 Mbit/s), full-speed (12 Mbit/s) and low-speed (1.5 Mbit/s). The applications of the ISP1521BE include Monitor hubs, Docking stations for notebooks, Internal hub for USB motherboards, Hub for extending Easy PCs and Hub boxes.

Parametrics

ISP1521BE absolute maximum ratings: (1)VCC, supply voltage 3.3 V: -0.5 to +4.6 V; (2)VREF(5V0), input reference voltage 5.0 V: -0.5 to +6.0 V; (3)VI(5V0), input voltage on 5 V buffers: -0.5 to +6.0 V; (4)VI(3V3), input voltage on 3.3 V buffers: -0.5 to +4.6 V; (5)VO(3V3), output voltage on 3.3 V buffers: -0.5 to +4.6 V; (6)Ilu, latch-up current: 100 mA; (7)Vesd, electrostatic discharge voltage: -4000 to +4000 V; (8)Tstg, storage temperature: -40 to +125℃.

Features

ISP1521BE features: (1)Self-powered capability; (2)USB suspend mode support; (3)Configurable number of ports; (4)Internal power-on reset and low voltage reset circuit; (5)Port status indicators; (6)Integrates high performance USB interface device with hub handler, Philips Serial Interface Engine (SIE) and transceivers; (7)Built-in overcurrent detection circuit; (8)Individual or ganged power switching, individual or global overcurrent protection, and non-removable port support by I/O pins configuration; (9)Simple I2C-bus (master/slave) interface to read device descriptor parameters, language ID, manufacturer ID, product ID, serial number ID and string descriptors from a dedicated external EEPROM, or to allow the microcontroller to set up hub descriptors; (10)Visual USB traffic monitoring (GoodLink) for the upstream facing port; (11)Uses 12 MHz crystal oscillator with on-chip Phase-Locked Loop (PLL) for low ElectroMagnetic Interference (EMI); (12)Supports temperature range from -40 to +70℃; (13)Available in LQFP80 package..
